TP-58
Features
* Reliable printer mechanism
* Ultra big roll diameter max 40 mm
* Strong power 1500 mAh
* Easy paper loading
* Label printing supported* Wireless connection
* Diagram/logo printing
* Long standby time
* Customized case color
* Supporting Android/windows/Mac OS
E-Brochure
| Mini 58mm thermal printer | |
| Mechanism | TP-58 |
| Printing method | Thermal dot line printing |
| Paper width | 58mm |
| Paper roll diameter | Max 40mm |
| Outside dimension | 103mm*75mm*46mm |
| Weight | 197g |
| Dot/Line | 16 Chinese /line or 32 English/Line |
| Speed | 90mm/s(in full power ) |
| Reliability | 1,000,000 characters |
| Printing Type | Languages, numbers, LOGO, diagram |
| Resolution | 8 dots/mm |
| Interface | RS-232/USB(by Optional) |
| Power supply | Rechargeable lithium battery 1500mAh(charging time 2 hours) |
| Adaptor | Input:AC90~230V,output:DC9V/2A |
| Standby time | Below 20uA |
| Abnormal detection | Out-paper. lower power. overheating |
| Paper loading method | Easy loading from front panel |
| Command set | ESC/POS |
| Standard accessories | user manual, adaptor, battery, cable |
| Cutting method | Manual Tearing |
| Optional: Can be 80mm | |
